Using Flame-Resistant and Arc-Rated Clothing to Mitigate Cold Stress
Workers in the electric utility industry face various hazards, and in cooler climates, this includes potential cold stress. Cold stress occurs when the skin’s temperature drops, lowering internal body temperature and inhibiting the body’s ability to warm itself. If unchecked, exposure to cold can lead to several medical conditions, including trench foot, chilblains, frostbite and hypothermia.
Flame-resistant (FR) and arc-rated (AR) garments can be worn by workers to help protect them from both cold stress and potential burn injuries due to arc flashes and flash fires. Employers must ensure workers wear the garments properly and consistently to minimize environmental effects. They must also train workers on how to manage their work in cold environments.
In a cold environment, much of the body’s energy is used to maintain its internal temperature. Over time, the body will begin to shift blood flow from the hands, feet, arms and legs to the core, causing rapid cooling of the extremities and any exposed skin.
When the body can no longer maintain its core temperature by constricting blood vessels, it shivers to increase heat production. Maximum severe shivering develops when the body temperature has fallen to 95 degrees Fahrenheit. At this point, hypothermia can occur.
Before hypothermia potentially occurs, however, even slight shivering or cold hands or feet can cause workers to lose focus, which can lead to errors and accidents. For workers who also face thermal hazards, errors may increase the risk of flash fire and arc flash.
Variables to Consider
The duration of a worker’s exposure to environmental conditions – including temperature, wind and precipitation – can contribute to cold stress. Following are some other variables to consider:
- Age/physical conditioning: A worker’s general fitness will affect their ability to tolerate and regulate temperature.
- Activity level: The degree of physical activity required for a job can affect a worker’s ability to stay warm. Physical activity may also lead to perspiration, which can create an additional hazard.
- Clothing: Both fabric and layering choices will impact the ability of garments to keep workers warm.
- Hydration: A worker’s consumption of warm, noncaffeinated liquids before and during work can help them maintain body warmth.
The most common way workers lose body heat in cold conditions is through conduction, which is when body heat is transferred through direct contact with an object (e.g., when workers sit on a cold bench or lie on cold ground). Conduction also occurs when workers’ clothing becomes cold. Body warmth is drawn out by the cold material, causing heat loss. This is particularly problematic when a worker is wearing a single, heavy outer layer.
Proper layering of several thinner garments can mitigate conduction. With layering, pockets of air are trapped between each garment and warmed by the wearer’s body heat, providing insulation from the cold.
Moisture in a worker’s clothing system may also contribute to loss of body heat. Perspiration and precipitation cause clothing to become wet and cling to the skin, eliminating the insulating layers of air between garments and the body. Water is a much better conductor of heat than air is, so when wet layers are in contact with the skin, heat is lost from the body much more rapidly, making cold stress a greater threat to the worker.
And while moisture-wicking PPE and a base layer can help protect workers against cold stress caused by perspiration, a layered garment system helps wearers avoid sweating in the first place. That’s because they have the flexibility to unzip or remove an outer layer to promote cooling.
Layering Best Practices
Effective layering for protection from cold stress requires layering for insulation as well as for protection against overheating and perspiration. Following are layering best practices that can be used when arc flash or flash fire is a potential hazard:
- Wear an insulating, water-resistant, water-repellent or waterproof FR/AR outer layer rated for the assessed hazard to protect against wind and precipitation.
- Wear a fleece FR/AR middle layer rated for the identified hazard.
- Wear an FR/AR base layer that will wick moisture away from the body.
- Wear head, face and hand protection – including balaclavas, skull or watch caps, and insulating gloves – made of non-melting fabrics that are rated for the hazard.
- Wear ANSI/ISEA 107-certified high-visibility FR/AR apparel as the outermost layer (e.g., a hi-vis FR/AR vest may be worn over a cold-weather FR/AR coat). Lack of visibility can compromise worker safety.
- Wear insulating, waterproof boots.
- Keep a change of dry FR/AR clothing available in case work clothes become wet.
- Choose clothing that fits properly; to maximize the insulating layers of air between garments, clothing should be neither too loose nor too tight.
Providing Appropriate Protection
To help provide maximum protection against thermal accidents, FR/AR garments must be worn fully zipped, buttoned and tucked. However, in cold environments, this can promote perspiration and exacerbate the possibility of cold stress.
To address this problem, workers can wear a layered garment system with inner layers that are fully rated to the thermal hazard. The outer FR/AR layers will provide additional, critical protection from thermal accidents, but workers will have the flexibility to open the closures or even remove an outer layer to manage perspiration.
When it comes to layering FR/AR garments for warmth, make sure to keep these three critical considerations in mind.
1. Always wear an FR/AR garment as the outermost layer. The garment’s rating must be equal to or greater than a reasonable estimate of the hazard.
2. FR/AR middle and base layers add critical elements of protection. In an arc flash event, the force of the blast may cause the outer garment to break open. Wearing appropriately rated middle and base layers helps protect against potential burn injury.
3. Non-FR/AR outerwear should never be worn over FR/AR garments. FR/AR garments are designed to self-extinguish once the ignition source is removed. During a flash fire or an arc flash, non-FR/AR outerwear will likely melt or ignite, causing injury and nullifying any FR/AR protection underneath.
When the temperature drops or the wind picks up, your workers can be exposed to significant cold stress hazards. Fortunately, employers have options for helping workers protect themselves from cold as well as from flash fire and arc flash injury. A comprehensive PPE system that incorporates several layered FR/AR garments provides much-needed insulation as well as the flexibility to stay comfortable as temperatures and workloads change throughout the day.
About the Author: Derek Sang is senior technical training manager at Bulwark Protection. He has been involved with the flame-resistant clothing industry in a variety of roles for over 20 years. Along with being a recognized subject matter expert, Sang is also a qualified safety sales professional; a certified environmental, health and safety professional; and a certified safety, health and environmental technician.
